Axis 570 Guía de usuario

User's GuideHigh Performance Multi-Protocol Print Servers for Virtually All Networks Axis Print ServersAXIS 570/670v3.0

AXIS 570/670 User’s Guide SNA Printing in the AS/400 environment 9 10. Use the command WRKCFGSTS *CTL xxxx*, where xxxx is the first 4 characters of

SNA Printing in the AS/400 environment AXIS 570/670 User’s Guide 10 4. Select the paper size for each paper bin from the Paper Size drop-down list a

AXIS 570/670 User’s Guide TN5250E Printing in the AS/400 environment 11 2. Type STRPRTWTR xxxxPRT01 on the AS/400 command line, where xxxxPRT01 is t

TN5250E Printing in the AS/400 environment AXIS 570/670 User’s Guide 12 8. Select IBM PRINTER DRIVER from the header.9. Make sure that the Printer D

AXIS 570/670 User’s Guide AS/400 IPDS over PPR/PPD Printing 13 AS/400 IPDS over PPR/PPD Printing Note:Before you begin:Configuring the AXIS 570e/670

AS/400 IPDS over PPR/PPD Printing AXIS 570/670 User’s Guide 14 Creating a PSF ConfigurationFollow the instructions below to create a PSF configurati

AXIS 570/670 User’s Guide AS/400 IPDS over PPR/PPD Printing 15 8. Enter a FGID number at the Font Identifier (FONT) line. A list of all supported FG

SNA Printing in the Mainframe Environment AXIS 570/670 User’s Guide 16 SNA Printing in the Mainframe EnvironmentConfiguring the Mainframe Host Syste

AXIS 570/670 User’s Guide SNA Printing in the Mainframe Environment 17 5. Select 3174 from the 3174/5494 Emulation Parameter drop-down list.6. Enter

SNA Printing in the Mainframe Environment AXIS 570/670 User’s Guide 18 IBM Mainframe8. Select the appropriate page properties and click the Submit I

AXIS 570/670 User’s Guide Read Me First 1 Read Me FirstTo get your print server quickly up and running, follow the instructions below:1. Connect the

AXIS 570/670 User’s Guide TN3270E Printing in the Mainframe environment 19 IBM MainframeTN3270E Printing in the Mainframe environmentCommunication b

TN3270E Printing in the Mainframe environment AXIS 570/670 User’s Guide 20 11. Repeat steps 5-10 for each session you want to set up.Note:12. Click

AXIS 570/670 User’s Guide TN3270E Printing in the Mainframe environment 21 Setting up the TN3270E serverThis section describes how to configure Micr

TN3270E Printing in the Mainframe environment AXIS 570/670 User’s Guide 22 Stage 2: SNA Server - AXIS 570/670 connection1. Select the new LUA and dr

AXIS 570/670 User’s Guide Mainframe IPDS over PPR/PPD Printing 23 Mainframe IPDS over PPR/PPD Printing Note:Configuring the Mainframe host1. Define

Mainframe IPDS over PPR/PPD Printing AXIS 570/670 User’s Guide 24 Configuring the AXIS 570e/670eFollow the instructions below to configure your AXIS

AXIS 570/670 User’s Guide Setup for Windows 95/98 & NT 25 Setup for Windows 95/98 & NTAXIS Print MonitorAXIS Print Monitor is the preferred

Setup for NDPS AXIS 570/670 User’s Guide 26 Peer-to-peer printing - This print method is recommended for smaller networks and requires that all user

AXIS 570/670 User’s Guide Setup for NetWare 27 As soon as the HP Gateway finds the AXIS 570/670, it will automatically create a public access printe

Setup for OS/2 AXIS 570/670 User’s Guide 28 NetWareA new window opens that allows you to create new print queues and connect print queues to the AXI

Safety notices AXIS 570/670 User’s Guide 2 Safety noticesTake some time to read through the safety notices before installing the AXIS 570/670. Pleas

AXIS 570/670 User’s Guide Set up for Macintosh 29 Client-server printing - This print method is suitable for larger networks and requires only one u

Setup for UNIX AXIS 570/670 User’s Guide 30 Setting the IP addressFollow the instructions below to set the IP address:1. Open the Chooser and select

AXIS 570/670 User’s Guide Management and configuration 31 Management and configurationIf you have assigned an IP address to your AXIS 570/670 you ar

Management and configuration AXIS 570/670 User’s Guide 32 Test ButtonAll Axis print servers are equipped with a test button. The functionality of th

AXIS 570/670 User’s Guide Product Overview 3 WindowsIBM MainframeIBM AS/400UNIXNetWareOS/2MacintoshProduct OverviewThe AXIS 570/670 is a LAN attache

Product Overview AXIS 570/670 User’s Guide 4 The AXIS 670 Print ServerThe AXIS 570e Print ServerThe AXIS 670e Print ServerLPT1 PrinterConnectorLPT2

AXIS 570/670 User’s Guide Product Overview 5 Hardware InventoryUnpack and check all the items using the following check list. Contact your dealer if

Connecting the Printer to the Network AXIS 570/670 User’s Guide 6 AXIS Online CDThe AXIS Online CD provides an easy-to-use electronic catalog, that

AXIS 570/670 User’s Guide Assigning an IP address 7 Assigning an IP addressTo establish communication with the TCP/IP network, an IP Address must be

SNA Printing in the AS/400 environment AXIS 570/670 User’s Guide 8 SNA Printing in the AS/400 environmentImportant!Configuring the AS/400 Host Syste
