Basic Acquisition Methods

AB SCIEX TripleTOF

5600/5600+ Instruments

46 of 116

System User Guide

D5033331 A

Figure 4-1 Ion optics path and parameters

Item Parameter Parameter

type

Use Scan type

1 Ion Source

Gas 1 (Gas 1)

Source and

Gas

The GS1 parameter controls the

nebulizer gas. The nebulizer gas helps

generate small droplets of sample flow

and affects spray stability and

sensitivity.

All

1 Ion Source

Gas 2 (Gas 2)

Source and

Gas

The GS2 parameter controls the flow of

heater gas, which helps evaporate the

solvent to produce gas phase sample

ions.

All

1Curtain Gas

(CUR)

Source and

Gas

The CUR parameter controls the gas

between the curtain plate and the

orifice plate. It prevents the

contamination of the ion optics.

All

1 Temperature

(TEM)

Source and

Gas

The TEM parameter controls the

temperature of the turbo gas in the

TurboIonSpray

probe or the

temperature of the probe in the heated

nebulizer (or APCI) probe.

All
